M12 Waterproof Connector Fast Locking Field Ethernet Assembly 4pins Sensor Connector
Description
• M12 Field wireable / installable connectors permit high flexibility for wiring cables in the field. It enables quick assembly and disassembly of differing cable lengths.
• The wire connection normally use soldering termination, crimping and screw termination.
Quick details
Core type: A.B.C.D
Contacts:3.4.5.8.12pins
Rated current: 4A
Rated AC/DC: 350V
Cable size: 0.34mm
Cable size AWG: 22
Mating Cycle: 500times
Temperature: -40°C~+80°C
Degree of protection: IP67 / 68
Material
Cable material: PUR/PVC
Shell material: copper/Zinc
Core material:PA
Insert/ Housing: TPU
Overmold material:PVC/TPU
Terminal material:Phosphor copper
Coupling nut/screw: Brass with nickel plated screw
Electrical Data
| Rated Current | 1.5A/2A/4A |
| Rated Voltage | 30V/60V/250V |
| Sealing | O-ring |
| Insolution resistance | ≧100mΩ |
| Contact resistance | ≦100mΩ |
| Cable diameter | ∅4~mm∅8mm |
| Shielding | Available |
| Gender | Female |
| General Characteristics |
| Number of contact | 3 | 4 | 5 | 8 | 12 | 17 |
| Locking system | screw M12*1.0 |
| Termination | solder, moulded on cable, crimp or screw clamp |
| Wire guage in mm² | 0.14/0.25/0.34/0.5 etc |
| Wire guage in AWG | 26/24/22/20 etc |
| Shell protection | IP67/IP68 |
| Mechanical operation | >500 mating cycles |
| Upper temperature | +85℃ |
| Lower temperature | -25℃ |
Product photos
Applications
● Standard sensor, actuator, encoder, servo motors
● Factory automation and process control
● Packaging, labeling and logistic devices
● Industrial instrumentation
● Commercial electronics PCBA
● Industrial safety light curtain, light grid, switches
● Power supply
● Fieldbus: DeviceNet, CANopen, Profibus, Ethernet, NMEA 2000
● LED display panel & outdoor LED lighting
Packsging & Shipping
1.Our general packing: PE bag and PE bag contons. General Carton size:40*30*30cm
2.Customized according to customer's request
Our service
1.100% high quality, all failed parts get free warranty within 30 days after received.
2. Accept 3 years warranty upon customer requirement.
3. Repairs parts are available within 10years; we will inform the EOL products to you from time to time
4. Free LOGO on the surface of over-molded connectors can be provided upon customer requirement.
5. Unique designed package for you can be provided upon customer requirement.
6. Special feature and service can be provided upon requirement.
